One supplier for all your ECAD tools

Browse our portfolio of ECAD software solutions

Component management
Keep track of your design data using a component database and version control, which is directly integrated with your hardware development tool and PCB design tool.
Schematic
All electronics design begin with drawing schematics. OrCAD Capture is the most used schematic tool in the industry, and is very intuitive and user friendly. Start a free trial today.
Simulation
Our simulators ensure that your design can live up to the requirements, and that the product will work as intended. Virtual simulation helps you save time and ressources on prototypes.
PCB Design & more
We have PCB design tools for all parts of the design process. From smaller designs to large, advanced high-speed boards. We provide a scalable solution for your exact needs.

Transform your PCBs with OrCAD X and Allegro X

Experience the power of a reimagined state-of-the-art platform for PCB design that is built on Allegros robustness and rebuilt with user-friendliness in mind.

Both OrCAD X and Allegro X for PCB design offer a vast suite of functionality and has the user in mind. From personalization and flexibility, to automation and cloud-collaboration.

Regardless of your team size, we have a solution for you that will maximize your productivity and significantly shorten our development cycle.

It all begins with a schematic

We offer tools for the entire process of electronics design. The first phase is schematics where you need a tool with high usability. Our schematic tool is OrCAD Capture, which is the most used amongst most of the country’s and world’s leading electronics developers.

You can easily pair your schematic tool with a component library for easy access to all the symbols and footprints needed for your design.

Simulation of your circuit & tests

You need to simulate your design to make sure it does not have any errors or mistakes. There are several freeware simulation tools out there that can handle this, however you can never be sure that the results from these are correct.

We offer some of the absolute best simulators on the market to test your designs. Our secure and powerful simulators can test your circuit for errors, which can turn out to be costly, if not found, and compromise the design quality.

Worldclass PCB layout

Once you have drawn and simulated your design, you can begin the layout process. Our PCB tool has been further developed and improved over the past years, both with regards to user interface and on the core technology.

You can now see your PCB in 3D viewing, which provides a much better overview of the finished result. When you make changes to the PCB, they are shown in real-time, and you can also run several checks to ensure the quality continuously.

The design is almost ready for production

When the design process is finished, it is almost ready for production. But before sending it to the PCB manufacturer, we recommend that you check your gerber files in a CAM tool. By doing so, you ensure that the PCB manufacturer can understand the files that your E-CAD systems produce. We offer some of the best CAM tools on the market for this part of the process.

The very last thing you need to consider is documentation. The manufacturer who assemble your design need documentation, and we have just the tool to complete this job and make sure that the work is handled faster and more streamlined each time.

Powering 300+ Nordic companies with the best EDA solutions

You're in good company

Component and data management systems

Access distributor databases and add components directly with OrCAD.

OrCAD CIP

Component database

With OrCAD Component Information Portal, you can track components and see where they are used in each project. Switch a component in no time!

  • Ready-to-go database solution with web interface
  • SiliconExpert integration
Get a free demo

OrCAD EDM

Version Control of designdata

OrCAD Engineering Data Management is the ideal tool for keeping track of versions and changes made during the electronics design process.

  • Team design
  • Version Control
Get a free demo

Save on costly resources with simulation

Imagine that you create a design and start using it in a real-life scenario. Suddenly, components on your PCB begin to fail, and the damage is done. These errors can easily be avoided by using a simulation tool to identify faults in your circuit and PCB before mass production.

If you want to know how, you should watch our webinar with our application engineer, Kristian, who shares his experiences with customers and how you can avoid falling into costly traps.

ECAD
Nordcad

More than 30 years experience with ECAD systems

We’ve been around since the 80s and know all the in’s and out’s of the electronics industry. We know what it takes to succeed with electronics design today, and our excellent team helps both new businesses and some of the largest enterprises with getting started with the right design tools.

We do much more than supply the best software to the industry. We provide our customers a complete solution that entails technology- and system development. Our team is specialised in building component databases that contain information on and for the entire company, resulting in a highly optimised workflow.

Our expert technicians can train you in using the tools, and they are also at your service on hotline support to answer any technical questions. We help you with everything from schematic, simulation and PCB design, and can guide you in choosing the next generation’s technologies.
